Inkle Loom Basics: Making Bands and Belts

Why an inkle loom deserves a place on your table

The inkle loom is one of the most forgiving pieces of equipment in textile craft. It has no treadles, no reed, no complicated tie-up, and the weft is simply your fingers and a length of yarn wound into a butterfly. What it does have is purpose: it makes strong, dense, warp-faced bands that are far tougher than anything a rigid heddle loom will produce at the same width. Bag straps, apron ties, dog leads, key fobs, decorative trim for a cushion, the waistband of a costume — these are the projects an inkle loom was born for. Bands are usually between 1 cm and 5 cm wide, and because the warp does all the work visually, you can plan a pattern on graph paper and watch it appear row by row.

If you can wind a warp and keep a consistent beat, you can weave on an inkle loom. The whole craft rewards patience far more than it rewards expensive kit.

Choosing yarn and working out your warp

Inkle bands are warp-faced, which means the warp threads sit side by side and the weft hides between them. That makes yarn choice straightforward: pick something smooth, strong and firmly plied. Perle cotton in size 8, crochet cotton, a sturdy 4-ply wool, or a smooth acrylic DK all work beautifully. Hairy or loosely spun yarns will fuzz together and make clean sheds impossible.

Width is governed by thread diameter and the number of ends. As a rough guide, DK weight gives about 1 cm of band per six ends, so a 24-end warp makes a band around 4 cm wide. For finer cotton you may need 30 to 40 ends for the same width.

Length needs a little arithmetic. Take your finished length, add roughly 50 cm for loom waste and knots, then add another 10 per cent for take-up and shrinkage as the band settles. A 1.5 m belt therefore wants a warp of about 2.15 m. Cut every thread to exactly the same length — a warping paddle, or simply looping the yarn round two chair backs at the right distance, keeps things honest.

Warping the loom step by step

  • Set the tensioning peg so the warp path gives you the length you calculated.
  • Attach the first thread to the front peg with a slip knot, then run it along the whole warp path, round the far peg and back, following the route your loom's manual shows.
  • Continue with each thread, keeping them flat and untwisted, until your count is complete. Group them in tens with a loose knot so you can check your numbers.
  • Tie the whole bundle to the front peg with a firm overhand knot, then tension the warp until it gives a low, even note when plucked. It should feel like a guitar string, not a washing line.
  • Now thread the heddles. On a typical inkle loom you make a string heddle for every other warp end, slipping each one onto the heddle rod in order. This is the fiddliest part of the whole process, so take your time and count as you go.

Once the heddle rod is in place, lift it and check that half your threads rise cleanly. Push the rod down and the other half should rise. If any thread refuses to move, you have missed a heddle.

Weaving the band

Wind your weft yarn into a butterfly — a figure-of-eight around your fingers and thumb — or use a small netting shuttle. Leave a 40 cm tail hanging at the side and pass the butterfly through the open shed. Beat the weft firmly against the previous row using the beater or the edge of the heddle rod.

Here is the trick that separates neat bands from ragged ones: before you beat, leave a tiny loop of weft at each selvedge rather than pulling it tight. The weft must be snug enough to be invisible but loose enough not to draw the edges inwards. Change the shed, pass back the other way, and beat again. Because the band is warp-faced, the weft should barely show at all — if you can see it clearly, your weft is too thick or your beat is too gentle.

Advance the warp every 10 to 15 cm by releasing the tension, turning the band forward on the front peg, and tightening again. Never weave so close to the heddle that you cannot open a clean shed.

Adding pattern with pick-up

Plain bands are lovely, but the real fun starts with pick-up. A flat stick, a spare heddle or even a smooth ruler lets you lift selected warp threads out of the shed to create geometric motifs, chevrons, letters or Baltic-style patterns. Draft your design on graph paper, one square per warp end, and read it row by row. Start with simple two-colour diagonals before attempting anything intricate — the rhythm of lift, pass, beat soon becomes second nature.

Finishing and putting your bands to work

Cut the warp from the loom leaving generous tails. Knot the ends in pairs, then either trim them neatly or braid them into a decorative fringe. For a belt or bag strap, fold the ends back and stitch them firmly, or attach them to a buckle or D-ring with a few rows of tight hand stitching.

A quick press with a steam iron, or a gentle hand wash and air dry, settles the weave and evens out any wobble in the selvedges. From there, the options are wide: two narrow bands stitched side by side make a sturdy belt, a single band becomes a lanyard or camera strap, and short offcuts turn into bookmarks, bracelets and Christmas decorations. Keep a notebook of warp counts and yarns — after three or four bands you will have your own reference library, and every one will be better than the last.
